CONCRETE WATERPROOFING, ADMIXTURES & SURFACE PROTECTION

WP ADMIX

Integral Waterproofing by Crystallisation

Overview

WP Admix is an advanced crystalline technology admixture formulated to waterproof and protect concrete structures. Added during batching, the admixture reacts chemically within the concrete mass to create insoluble crystalline formations that block capillaries and fine pores. The result is an integral waterproofing barrier that remains effective for the life of the concrete.

Benefits

•Exceptional durability
•Ensures maximum waterproofing performance of concrete
•Maintains integrity under hydrostatic pressure exceeding 7 bar
•Provides long-term durability across wide temperature variations
•Minimizes shrinkage and crack formation
•Shields against certain aggressive agents including chloride-induced corrosion of steel reinforcement
•Self-seals static cracks up to 0.4 mm
•Formulated in accordance with AS 1478.1-2000
•Cost-effective integral waterproofing solution.

General Application

•Tunnels
•Basements
•Water-retaining and substructure concrete elements
•Housing
•Marine applications
•Water Tanks
•Reservoirs
•Water retaining structures

DOWNLOAD TDS DOWNLOAD SDS

WP CONCENTRATE

Waterproofing by Crystallisation

Overview

Galaxie WP Concentrate is a surface-applied crystalline waterproofing treatment for concrete. Supplied as a dry powder consisting of Portland cement, specially treated quartz sand and a proprietary blend of active chemicals, it is mixed with water on site and applied directly to prepared concrete surfaces. No primer or separate bonding agent is required.Once applied, the active chemicals react with free lime and moisture in the concrete capillary system to form insoluble crystalline complexes. These crystals progressively block capillaries and minor shrinkage cracks, preventing water ingress even under sustained hydrostatic pressure. The treatment remains breathable water vapour can still pass through the structure. Crystal growth continues as long as moisture and free lime are present, giving Galaxie WP Concentrate ongoing self-sealing capability throughout the life of the concrete.In addition to waterproofing, WP Concentrate protects concrete against seawater, wastewater, aggressive groundwater and certain chemical solutions. It is potable water approved and is suitable for water storage tanks and reservoirs.

Benefits

•Integral crystalline waterproofing that becomes part of the concrete matrix
•Withstands water pressure exceeding 12 bar at 28 days
•Self-sealing crystal growth continues in the presence of moisture and free lime
•Breathable allows water vapour transmission while blocking liquid water
•Potable water approved suitable for drinking water tanks and reservoir
s•Protects against seawater, wastewater, aggressive groundwater and chemical solutions
•Non-combustible tested to BS 476-4
•Can be applied as a slurry coat or dry-shake to freshly placed concrete slabs•Suitable for brush, roller or spray application

General Application

•Basement retaining walls
•Concrete slabs — floor, roof and balcony•Construction joints
•Water-retaining structures
•Swimming pools
•Sewage treatment plants and channels
•Potable water tanks and reservoirs
•Blinding concrete and construction joint treatment

DOWNLOAD TDS DOWNLOAD SDS

WP PREMIX

Waterproofing by Crystallisation

Overview

WP Premix is a single-component crystalline waterproofing slurry for concrete. Supplied as a dry powder requiring only the addition of clean water on site, it can be used as a standalone damp-proofing treatment or as a second coat over Galaxie WP Concentrate where a two-coat system is specified. Applied as a second coat, WP Premix chemically reinforces the crystalline layer and produces a harder surface finish.WP Premix prevents water and liquid penetration from any direction by triggering a catalytic reaction with free lime and moisture in the concrete capillary system, forming insoluble crystalline complexes that permanently block capillaries and pores. The treatment becomes an integral part of the substrate and cannot puncture, tear or delaminate.

Benefits

•Resists hydrostatic pressure exceeding 7 bar at 28 days•Becomes an integral part of the concrete substrate cannot puncture, tear or come apart•Breathable allows water vapour to pass while blocking liquid water•Resistant to aggressive chemicals•Non-toxic and potable water approved•Can be applied to damp surfaces does not require dry weather or a dry substrate•Can be applied to positive or negative side of concrete•No surface priming or levelling required prior to application•No sealing, lapping or finishing of seams at corners, edges or joints required•Does not require protection during backfilling or placement of steel, wire mesh or other materials•Permanent

General Application

•Reservoirs
•Sewage and water treatment plants
•Secondary containment structures
•Tunnels and underground structures
•Foundations and basement walls
•Parking structures
•Swimming pools

DOWNLOAD TDS DOWNLOAD SDS

WP FLEX

Cementitious Polymer Coating

Overview

Galaxie WP FLEX is a two-component acrylic modified cementitious waterproofing membrane for use on concrete, masonry and most construction substrates. Mixed on site, itforms a seamless, flexible, hardwearing membrane that waterproofs and resurfaces structures while providing high resistance to carbonation and chloride ion penetration.WP FLEX provides an effective barrier to waterborne salts and atmospheric gases. A 1 mm coating provides an anti-carbonation cover equivalent to over 80 mm of concrete. Unlike conventional coatings requiring the concrete to cure for 7–28 days, WP FLEX can be applied to 24-hour-old concrete, giving immediate protection. WP FLEX should not be left exposed; it should be protected by tiles or an appropriate protective coating where required.

Benefits

·Waterproof resists up to 15 bar (150 m head) positive pressure and 3 bar (30 m head) negative pressure
·Flexible 150% elongation
·Non-toxic suitable for potable water tanks and reservoirs
·Excellent adhesion to both porous and non-porous surfaces
·Breathable repels liquid water while allowing substrate vapour to escape
·High resistance to carbon dioxide and chloride ion diffusion
·A 1 mm coating provides anti-carbonation protection equivalent to over 80 mm of concrete
·Can be applied to 24-hour-old concrete no extended curing wait required
·Seamless membrane eliminates joint failure risk associated with sheet membranes
·Light trafficable once cured
·Can be spray applied using a hopper gun
·Good chemical resistance to gasoline, diesel, oil, sodium hydroxide, calcium chloride, de-icing salts and treated sewage

General Application

•Basements and below ground structures
Water tanks and reservoirs (potable and non-potable)
•Swimming pools
•Bathroom, wet areas and planter boxes
•Protected roof waterproofing
•Seawater channels and marine structures
•Refacing and protection of concrete surfaces
•Sealing and coating of tie bar holes
•Protection against carbonation and chloride attack
•Tile fixing in water-retaining structures

DOWNLOAD TDS

WP SDW 1

Silicate Densifier and Water proofer

Overview

Galaxie SDW 1 is a chemically modified silicate densifier and waterproofing solution designed to penetrate concrete substrates. It reacts with free lime (calcium hydroxide) and moisture to form an insoluble calcium silicate hydrate (CSH) gel within pores, capillaries, and micro-cracks, permanently densifying the concrete matrix. By densifying the concrete, the gel creates a sub-surface barrier against the ingress of water and contaminants such as chloride ions.

Benefits

•Water-based, non-toxic, VOC-free
•Long-term performance with no requirement for reapplication under normal service conditions
•Fully trafficable once cured
•Allows easy identification and remediation of persistent leaks or cracks without the need to remove membranes
•Capable of sealing non-moving shrinkage cracks up to 2.0 mm, subject to substrate condition
•Reduction of chloride diffusion coefficient by up to 89%
•Water permeability reduced by up to 70%
•Can increase surface hardness to approximately 6–8 on the Mohs scale
•Allows >80% moisture vapour permeability

General Application

•Rooftops & Podium Decks
•Car-Parks
•Road & Rail Bridge Decks
•Wharf Decks & Marine Structures
•Airport Runways, Taxiways, Aprons

DOWNLOAD TDS DOWNLOAD SDS

WP SDW 7

Crystalline Silicate Waterproofer & Hardener

Overview

WP SDW 7 is a chemically modified silicate densifier and waterproofing solution designed to penetrate deep into concrete substrates. Its biowetting formulation lowers surface tension so the product wets out fast and penetrates further than standard silicate sealers, migrating through the concrete's capillary network to reach fine pores that untreated products cannot.It reacts with free lime (calcium hydroxide) and moisture in the concrete to form an insoluble calcium silicate gel within the pores, capillaries and micro-cracks. This gel permanently densifies the concrete matrix, blocks the pathways used by water and waterborne salts, and seals static cracks up to 2.0 mm wide. Because the reaction happens below the surface rather than forming a film, the concrete keeps its natural texture and stays fully trafficable, there's no risk of the bubbling, peeling or blistering you get with film-forming coatings.The gel stays active for the life of the structure. If a hairline crack opens up later, moisture reaching it triggers the same reaction and reseals it no reapplication needed.

Benefits

•Biowetting formulation for fast, even wetting and deeper penetration.
•Water-based, non-toxic, low-odour.
•Seals static concrete cracks up to 2.0 mm wide.
•Self-healing reseals future hairline cracks on contact with moisture, no reapplication needed.
•Reduces chloride diffusion coefficient by up to 89%, protecting reinforcing steel.
•Reduces water permeability by up to 70%.
•Fully trafficable immediately after the first water-cure cycle no site downtime.
•No film to bubble, peel or blister concrete keeps its natural surface texture and grip.
•Resists heavy mechanical wear, abrasion and vehicle traffic.

General Application

•Infrastructure & asset protection: multi-level car parks, road and rail bridge decks, airport runways, taxiways and aprons.
•Civil & marine structures: wharf decks, concrete piers, splash-zone infrastructure, marine retaining walls.
•Commercial building envelopes: exposed concrete rooftops, podium decks, facades, pre-cast panels.
•Water management: water-retaining structures, containment tanks, storm channels, reservoirs.
•Internal wet areas: under-tile waterproofing for commercial shower recesses and non-glazed tiled zones.

DOWNLOAD TDS DOWNLOAD SDS

WP WR

Silane-Siloxane Water Repellent

Overview

Galaxie WR is a water based, silane-siloxane system, which penetrates deeply into porous substrates to allow for a bonded hydrophobic lining to the pores. This treatment significantly reduces absorption of water and waterborne salts but still allows the passage of water vapour. The solution does not produce any discoloration of the substrate and has excellent resistance to weathering.

Benefits

•Water based system
•Provides an invisible water repellent surface.
•Green product, VOC free
•Allows the surface 100% transpiration
•Maintains the texture and colour of the treated surface
•Reduces efflorescence and surface salts
•Reduces cleaning costs

General Application

•External waterproofing of concrete, concrete blocks, brickwork and stone
•Treatment of rising and salt damp•Reduction of sand stone decay due to attack by salts and low pH precipitation
•Prevention of moss growth & dirt retention on pavers, walls and roofs
•Elimination of white salt spotting on brickwork

DOWNLOAD TDS DOWNLOAD SDS

SBR 46

Polymer Latex Additive

Overview

Reinjekt 2 is a pre-installed multiple-injection hose system that eliminates the need for concrete drilling at construction joints. Designed for contractors who need a reliable, cost-effective waterproofing solution that can be installed quickly during construction and re-injected on demand if leakage occurs.Installed as a joint packing before concrete is poured, the system covers the entire construction joint through a dedicated hose — no drilling required later. This means injection access is guaranteed from day one, saving time and cost if remedial waterproofing is ever needed.Reinjekt 2 is constructed from specially formulated plastic with special slots that prevent the infiltration of concrete water and laitance during casting, but open when internal pressure is applied. Its flexible nature allows it to follow contours and it should be placed in 10 metre lengths, or up to 30 metres if required.

Benefits

•Economical: simple parts and accessories reduce labour and material costs
•Fast installation: clips and pre-cut lengths mean minimal site disruption and no specialist equipment needed
•Can be injected with all currently available grouting materials, including PU resin, EP resin, AC resin and ultra-fine cement
•Repeated injection possible when using acrylic resins only — re-access the joint any time in the future without breaking out concrete
•Can withstand 12 metre head of concrete

General Application

•Construction joints in impermeable concrete structures
•Interface joints of concrete slabs and shotcrete sprays
•Between reinforcement bars where later injection may be required
•Areas requiring scheduled injection without concrete drilling

DOWNLOAD TDS DOWNLOAD SDS

REINJEKT 2

Multi Injection Construction Hose

Overview

Benefits

•Economical: simple parts and accessories reduce labour and material costs•Fast installation: clips and pre-cut lengths mean minimal site disruption and no specialist equipment needed•Can be injected with all currently available grouting materials, including PU resin, EP resin, AC resin and ultra-fine cement•Repeated injection possible when using acrylic resins only — re-access the joint any time in the future without breaking out concrete•Can withstand 12 metre head of concrete

General Application

•Construction joints in impermeable concrete structures•Interface joints of concrete slabs and shotcrete sprays•Between reinforcement bars where later injection may be required•Areas requiring scheduled injection without concrete drilling

DOWNLOAD TDS

High performance chemical solutions for building and civil construction industry.
